Bow | SRAM Rival XPLR |

43 000 SEK

A pure gravel race machine built for one obsession: speed. BOW is engineered for riders who refuse to compromise—those who attack, dominate, and cross the line first.?

With its lightweight carbon frame and refined aerodynamic efficiency, every watt translates into raw acceleration. The Zipp 303 XPLR wheelset cuts through air and terrain alike, while SRAM Rival XPLR AXS delivers wireless precision and instant shifts when it matters most. ??This is gravel racing at its purest: relentless, light, and uncompromisingly fast.

Specifications

Frameset

Frame

Allebike Bow / Carbon frame / internal cable routing / flat mount disc brake / 12x142mm thru-axle / UDH

Fork

Allebike Bow / Internal brake hose routing / tapered carbon steerer / flat mount disc brake / 12x100mm thru-axle

Wheelset

Wheels

Zipp 303 XPLR S / Carbon

Tyres

Zipp Goodyear Inter XPLR / 45 mm

Drivetrain

Shifters

SRAM Rival eTap AXS HRD shift-brake system / 1x13-speed

Rear Derailleur

SRAM Rival XPLR AXS

Crankset

SRAM XPLR AXS Power Meter / 170 mm / 44T

Bottom Bracket

SRAM DUB Pressfit

Cassette

SRAM XPLR XG-1351 / 10-46T / 13-speed

Chain

SRAM CN Rival E1

Components

Brakes

SRAM Rival AXS HRD shift-brake system / 140 mm + 160 mm rotors

Saddle

Selle Italia X Light

Seatpost

Allebike / carbon

Handlebar

FSA Adventure

Stem

FSA Adventure

Headset

FSA

Bar Tape

Selle Italia

Pedals

Sold separately

Other

Weight: 8.95 kg (size M)

Maximum weight rider: 120 kg


Technical specifications are subject to change without prior notice due to component availability and other factors.



 S
M
L
XL
A. Steerertube height130130157183
B. Top tube length545545567590
C. Reach375375390405
D. Stack555555580605
E. Headtube angle71,5°71,5°71,5°71,5°
F. Seattube521 521 545 569
G. Chainstay length418 418 418 418
H. Seattube angle73°73°73°73°
I. BB drop75757575
J. Wheelbase98898810111041
K. Fork length390390390390
L. Stem length709090100
M. IRL Reach435455470500
N. IRL Stack595600625653

All measurementare are mentioned in MM unless otherwise is stated
